Energy Metering

Manufacturer

Series

Packaging

Product Status

Package / Case

Mounting Type

Operating Temperature

Current - Supply

Measurement Error

Input Impedance

Voltage - I/O High

Voltage - I/O Low

Meter Type

Supplier Device Package

Grade

Voltage - Supply

Qualification

Mfr Part #	Quantity	Price	Series	Package	Product Status	Package / Case	Mounting Type	Operating Temperature	Current - Supply	Measurement Error	Input Impedance	Voltage - I/O High	Voltage - I/O Low	Meter Type	Supplier Device Package	Grade	Voltage - Supply	Qualification
LTC2946IMS#PBF IC ENERGY MONITOR I2C 16MSOP Linear Technology (Analog Devices, Inc.) Datasheet	1,228 In Stock	1 : $11.47 10 : $105.50 37 : $374.07 111 : $989.01 259 : $2,193.73 518 : $4,102.56 1,036 : $7,531.72 Tube		Tube	Active	16-TFSOP (0.118", 3.00mm Width)	Surface Mount	-40°C ~ 85°C	900µA	0.4%	-	-	-	Single Phase	16-MSOP	-	2.7 V ~ 100 V	-
ADM1293-1BACPZ IC MONITOR QUAD UV/OV 16LFCSP Linear Technology (Analog Devices, Inc.) Datasheet	82 In Stock	1 : $10.65 10 : $97.90 25 : $234.50 80 : $660.80 230 : $1,807.80 440 : $3,234.00 945 : $6,369.30 Tray		Tray	Active	16-WQFN Exposed Pad, CSP	Surface Mount	-40°C ~ 105°C	3.6mA	-	-	1.1V	0.4V, 0.8V, 1.5V	Single Phase	16-LFCSP-WQ (4x4)	-	2.95 V ~ 20 V	-
ADM1294-1AACPZ IC MONITOR QUAD UV/OV 16LFCSP Linear Technology (Analog Devices, Inc.) Datasheet	67 In Stock	1 : $17.16 10 : $157.70 25 : $378.00 80 : $1,065.60 230 : $2,911.80 440 : $5,214.00 Tray		Tray	Active	16-WQFN Exposed Pad, CSP	Surface Mount	-40°C ~ 105°C	3.6mA	-	-	1.1V	0.4V, 0.8V, 1.5V	Single Phase	16-LFCSP-WQ (4x4)	-	2.95 V ~ 13 V	-
CS5490-ISZ IC ENERGY METER 2-CH 16SOIC Cirrus Logic Datasheet	171 In Stock	1 : $4.71 48 : $192.00 144 : $499.68 1,008 : $2,509.92 Bulk		Bulk	Active	16-SOIC (0.154", 3.90mm Width)	Surface Mount	-40°C ~ 85°C	3.9mA	0.1%	30kOhm, 2MOhm	-	-	2 x Single Phase	16-SOIC	-	3 V ~ 3.6 V	-
AD7755AARS ENERGY METERING IC Linear Technology (Analog Devices, Inc.) Datasheet	3,010 Marketplace	180 : $300.60 Bulk		Bulk	Active	24-SSOP (0.209", 5.30mm Width)	Surface Mount	-40°C ~ 85°C	2mA	0.1%	390kOhm	2.4V, 4.5V	0.8V, 0.5V	Single Phase	24-SSOP	-	4.75 V ~ 5.25 V	-
ATM90E32AS-AU-Y 48-TQFP, IND TEMP, 1.8V/3V, TRAY Roving Networks (Microchip Technology) Datasheet	14,736 In Stock	1 : $3.64 25 : $83.50 100 : $302.00 Tray		Tray	Active	48-TQFP	Surface Mount	-40°C ~ 85°C	13mA	0.5%	50kOhm, 80kOhm, 120kOhm	3.2V, 5.5V	0.4V, 0.8V	3 Phase	48-TQFP (7x7)	-	2.8 V ~ 3.6 V	-
LTC2946HDE-1#PBF WIDE RANGE I2C ENERGY MONITOR (/ Linear Technology Datasheet	427 Marketplace	31 : $303.80 Bulk		Bulk	Active	16-WFDFN Exposed Pad	Surface Mount	-40°C ~ 125°C	900µA	0.5%	-	-	-	Single Phase	16-DFN (4x3)	-	2.7 V ~ 100 V	-
LTC2946IDE-1#PBF POWER SUPPLY SUPPORT CIRCUIT Linear Technology Datasheet	1,365 Marketplace	39 : $304.59 Bulk		Bulk	Active	16-WFDFN Exposed Pad	Surface Mount	-40°C ~ 85°C	900µA	0.4%	-	-	-	Single Phase	16-DFN (4x3)	-	2.7 V ~ 100 V	-
AD7756AN ENERGY METERING IC Linear Technology (Analog Devices, Inc.) Datasheet	1,920 Marketplace	162 : $301.32 Bulk	AD7756x	Bulk	Active	20-DIP (0.300", 7.62mm)	Through Hole	-40°C ~ 85°C	3mA	±0.4%	390kOhm	2.4V, 4V	0.8V, 0.4V	2 x Single Phase	20-DIP	-	4.5 V ~ 5.5 V	-
ADE9153AACPZ 1 PH MTR IC W/AUTO CALIBRATION Linear Technology (Analog Devices, Inc.) Datasheet	403 In Stock	1 : $9.57 10 : $86.40 25 : $206.00 80 : $572.80 230 : $1,570.90 440 : $2,741.20 945 : $5,131.35 Tray		Tray	Active	32-WFQFN Exposed Pad, CSP	Surface Mount	-40°C ~ 85°C	9.3mA	0.25%	113kOhm, 256kOhm, 7.8MOhm	2.4V, 2.5V	0.8V, 0.4V	Single Phase	32-LFCSP (5x5)	-	2.97 V ~ 3.63 V	-
