PACKAGING	QUANTITY	UNIT PRICE	EXT PRICE
{{ p.name }}	{{ numberFormat(p.buyQty) }}	{{ priceFormat(p.unitPrice) }}	{{ priceFormat(p.totalPrice) }}
Total Amount: {{ priceFormat(quotes.total) }} (including {{ priceFormat(quotes.fee) }} fee)

Mfr Part #	Quantity	Price	Series	Package	Product Status	Features	Connector Type	Contact Finish	Voltage Rating	Mounting Type	Number of Positions	Pitch	Number of Rows	Operating Temperature	Number of Positions Loaded	Termination	Connector Usage	Connector Style	Contact Finish Thickness	Current Rating (Amps)
2392859-1 Z-PACK A/B REC ASY 125P 2MMHM EO TE Connectivity AMP Connectors Datasheet	737 In Stock	Active	Z-PACK	Tray	Active	-	Receptacle, Female Sockets	Gold	500VAC	Board Edge, Through Hole, Right Angle	125	0.079" (2.00mm)	5	-55°C ~ 125°C	All	Press-Fit	Backplane	AB 25	30.0µin (0.76µm)	1.5 A
2392856-1 Z-PACK/C RAF 55P EON TE Connectivity AMP Connectors Datasheet	877 In Stock	Active	Z-PACK	Tray	Active	Upper Shield	Receptacle, Female Sockets	Gold	500VAC	Board Edge, Through Hole, Right Angle	55	0.079" (2.00mm)	5	-55°C ~ 125°C	All	Press-Fit	Backplane	C 11	50.0µin (1.27µm)	1.5 A
104112-E 2MM HM A 110POS F VERT 3.7MM TE Connectivity ERNI Datasheet	30 In Stock	Active	ERMET	Tray	Active	Upper Shield	Receptacle, Female Sockets	Gold	-	Through Hole	110	0.079" (2.00mm)	5	-55°C ~ 125°C	All	Press-Fit	-	A 22	-	-
4-2271013-0 CELLO, PIN HDR, 96PIN, TH, RA, F TE Connectivity AMP Connectors Datasheet	1,627 In Stock	Active	DIN 41612	Tray	Active	Mounting Clips	Header, Male Pins	Gold	-	Through Hole, Right Angle	96	0.100" (2.54mm)	3	-55°C ~ 105°C	All	Solder	-	C	3.00µin (0.076µm)	2 A
3-5106081-0 CONN HEADER 77POS 2MM PRESS-FIT TE Connectivity AMP Connectors Datasheet	322 In Stock	Active	Z-PACK	Bulk	Active	Board Guide	Header, Male Pins	-	500Vrms	Through Hole	77 (55 + 22 Ground)	0.079" (2.00mm)	5 + 2	-55°C ~ 125°C	All	Press-Fit	Backplane	C 11	-	1.5 A
3-5100147-0 CONN RECEPT 110POS 2MM PRESS-FIT TE Connectivity AMP Connectors Datasheet	209 In Stock	Active	Z-PACK	Tube	Active	-	Receptacle, Female Sockets	Gold	500Vrms	Board Edge, Through Hole, Right Angle	110	0.079" (2.00mm)	5	-55°C ~ 125°C	All	Press-Fit	-	A 22	30.0µin (0.76µm)	1.5 A
5646530-1 CONN HEADER 127POS 2MM PRESS-FIT TE Connectivity AMP Connectors Datasheet	105 In Stock	Active	Z-PACK	Bulk	Active	-	Header, Male Pins	-	500Vrms	Through Hole	127 (95 + 32 Ground)	0.079" (2.00mm)	5 + 2	-55°C ~ 125°C	All	Press-Fit	-	AB 19	-	1.5 A
17211102102 CONN RECEPT 110POS 2MM PRESS-FIT HARTING Datasheet	1,013 In Stock	Active	har-bus® HM	Tube	Active	-	Receptacle, Female Sockets	Gold	-	Through Hole, Right Angle	110	0.079" (2.00mm)	5	-55°C ~ 125°C	All	Press-Fit	CompactPCI J1/J4	A 22	-	1 A
17211101102 CONN RECEPT 110POS 2MM PRESS-FIT HARTING Datasheet	159 In Stock	Active	har-bus® HM	Tube	Active	Upper Shield	Receptacle, Female Sockets	Gold	-	Through Hole, Right Angle	110	0.079" (2.00mm)	5	-55°C ~ 125°C	All	Press-Fit	CompactPCI J1/J4	A 22	-	1 A
17051332602 CONN HEADER 133POS 2MM PRESS-FIT HARTING Datasheet	28 In Stock	Active	har-bus® HM	Tube	Active	-	Header, Male Pins	Gold or Gold-Palladium	-	Through Hole	133 (95 + 38 Ground)	0.079" (2.00mm)	5 + 2	-55°C ~ 125°C	All	Press-Fit	Compact PCI P3, VME JO	B 19	-	1 A
