Wire to Board

Mfr Part #	Quantity	Price	Series	Package	Product Status	Features	Color	Mounting Type	Wire Gauge	Pitch	Operating Temperature	Mating Orientation	Positions Per Level	Housing Material	Contact Material - Plating	Clamp Material - Plating	Screw Material - Plating	Torque - Screw	Screw Thread	Wire Termination	Current	Number of Levels	Voltage
2913600000 PRINTED CIRCUIT BOARD TERMINALS, Weidmuller Datasheet	22 In Stock	1 : $1.73 10 : $13.10 44 : $47.96 88 : $94.16 264 : $245.52 528 : $448.80 1,012 : $779.24 5,016 : $3,410.88 Tube	Omnimate MTS	Tube	Active	Push Button Actuated	Black	Through Hole	12-20 AWG	0.197" (5.00mm)	-50°C ~ 120°C	Horizontal with Board	2	Polyamide (PA9T), Nylon 9T	Copper Magnesium - Tin Plated	-	-	-	-	Screwless - Leg Spring, Push-In Spring	18.5 A	1	300 V
691101810004 WR-TBL TERMINAL BLOCK - WIRE PRO Würth Elektronik Midcom Datasheet	170 In Stock	1 : $4.41 10 : $40.40 100 : $360.00 250 : $790.00 500 : $1,470.00 1,000 : $2,720.00 Box	WR-TBL Series 1018	Box	Active	Interlocking (Side)	Blue	Through Hole	14-26 AWG	0.394" (10.00mm)	-40°C ~ 105°C	Horizontal with Board	4	Polyamide (PA66), Nylon 6/6	Brass - Tin Plated	Steel, Stainless	Steel - Zinc Plated	0.3 Nm (2.6 Lb-In)	M3	Screw - Leaf Spring, Wire Guard	16 A	1	250 V
691101810101 WR-TBL TERMINAL BLOCK - WIRE PRO Würth Elektronik Midcom Datasheet	395 In Stock	1 : $1.41 10 : $12.90 100 : $115.00 250 : $252.50 500 : $470.00 1,000 : $870.00 Box	WR-TBL Series 1018	Box	Active	Interlocking (Side)	Blue	Through Hole	14-26 AWG	-	-40°C ~ 105°C	Horizontal with Board	1	Polyamide (PA66), Nylon 6/6	Brass - Tin Plated	Steel, Stainless	Steel - Zinc Plated	0.3 Nm (2.6 Lb-In)	M3	Screw - Leaf Spring, Wire Guard	16 A	1	250 V
691410120006 WR-TBL TERMINAL BLOCK - SCREWLES Würth Elektronik Midcom Datasheet	239 In Stock	1 : $4.35 10 : $39.90 100 : $355.00 250 : $780.00 500 : $1,450.00 1,000 : $2,680.00 Box	WR-TBL Series 4101	Box	Active	Push Button Actuated	Black	Through Hole	18-24 AWG	0.138" (3.50mm)	-40°C ~ 110°C	45° (135°) Angle with Board	6	Polyamide (PA66), Nylon 6/6	Brass - Tin Plated	Steel, Stainless	-	-	-	Screwless - Leg Spring, Push-In Spring	7 A	1	300 V
691410120007 WR-TBL TERMINAL BLOCK - SCREWLES Würth Elektronik Midcom Datasheet	190 In Stock	1 : $5.20 10 : $47.60 100 : $424.00 250 : $930.00 500 : $1,730.00 1,000 : $3,200.00 Box	WR-TBL Series 4101	Box	Active	Push Button Actuated	Black	Through Hole	18-24 AWG	0.138" (3.50mm)	-40°C ~ 110°C	45° (135°) Angle with Board	7	Polyamide (PA66), Nylon 6/6	Brass - Tin Plated	Steel, Stainless	-	-	-	Screwless - Leg Spring, Push-In Spring	7 A	1	300 V
691410120003 WR-TBL TERMINAL BLOCK - SCREWLES Würth Elektronik Midcom Datasheet	480 In Stock	1 : $2.36 10 : $21.60 100 : $193.00 250 : $422.50 500 : $785.00 1,000 : $1,460.00 Box	WR-TBL Series 4101	Box	Active	Push Button Actuated	Black	Through Hole	18-24 AWG	0.138" (3.50mm)	-40°C ~ 110°C	45° (135°) Angle with Board	3	Polyamide (PA66), Nylon 6/6	Brass - Tin Plated	Steel, Stainless	-	-	-	Screwless - Leg Spring, Push-In Spring	7 A	1	300 V
TBLH12V-500-03BK TERMINAL BLOCK, SCREWLESS, HIGH CUI Devices Datasheet	1,205 In Stock	1 : $2.38 10 : $18.00 25 : $41.75 50 : $75.00 100 : $146.00 250 : $320.00 500 : $585.00 1,000 : $1,060.00 5,000 : $4,650.00 Box	TBLH12V-500	Box	Active	-	Black	Surface Mount	16-24 AWG	0.197" (5.00mm)	-40°C ~ 130°C	Vertical with Board	3	Liquid Crystal Polymer (LCP)	Copper Alloy - Tin Plated	-	-	-	-	Screwless - Push Button Clamp	10 A	1	300 V
TBLH12V-381-02BK TERMINAL BLOCK, SCREWLESS, HIGH CUI Devices Datasheet	2,079 In Stock	1 : $1.83 10 : $12.90 25 : $30.00 50 : $54.50 100 : $109.00 250 : $230.00 500 : $435.00 1,000 : $770.00 5,000 : $3,150.00 Box	TBLH12V-381	Box	Active	-	Black	Surface Mount	16-24 AWG	0.150" (3.81mm)	-40°C ~ 130°C	Vertical with Board	2	Liquid Crystal Polymer (LCP)	Copper Alloy - Tin Plated	-	-	-	-	Screwless - Push Button Clamp	10 A	1	300 V
TBLH11-500-02BK TERMINAL BLOCK, SCREWLESS, HIGH CUI Devices Datasheet	2,770 In Stock	1 : $1.18 10 : $8.30 25 : $19.25 50 : $35.00 100 : $70.00 250 : $147.50 500 : $280.00 1,000 : $500.00 5,000 : $2,000.00 Box	TBLH11-500	Box	Active	-	Black	Surface Mount	16-24 AWG	0.197" (5.00mm)	-40°C ~ 130°C	Horizontal with Board	2	Liquid Crystal Polymer (LCP)	Copper Alloy - Tin Plated	-	-	-	-	Screwless - Push Button Clamp	10 A	1	300 V
WJ128-7.5-09p-14-RNA 9 position PCB push-in spring co RNA (Reliance North America) Datasheet	50 Marketplace	50 : $183.00 100 : $348.00 250 : $792.50 500 : $1,470.00 1,000 : $2,780.00 2,500 : $6,925.00 5,000 : $13,450.00 Tape & Box (TB)		Tape & Box (TB)	Active	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
